TJH72 12-02-2012 09:50:13 65.31.36.177 Report to Moderator	My mother has a 1948 John Deere M that has been sitting in a barn for 6 or 7 years. I pulled it out of the barn a couple of weeks ago and I have been trying to get it running again. I got a new battery, changed the spark plug, put fresh gas in it and I do not think it is getting any spark. Is there an in line fuse that might be bad? If so, where? It seems like it is something simple I am overlooking. Also, are there any other common areas I should check? I thought I would ask before I really start tearing things part. Thanks for the help. TJH72 [Reply]   [No Email]
Johndeere39h 12-04-2012 14:48:26 66.41.113.151 Report to Moderator	Re: 1948 John Deere M in reply to TJH72, 12-02-2012 09:50:13   Thanks for the tip, will check the voltage at the coil, Could be the wiring, someone years.....ago put a ton of electrical tape around all the wires under the hood, Well at least I have extra parts if that's it, Thanks for the help Jeff [Reply]  [No Email]
CaseRider 12-04-2012 07:30:17 64.134.152.175 Report to Moderator	Re: 1948 John Deere M in reply to TJH72, 12-02-2012 09:50:13   Quoting Removed, click Modern View to see [Reply]  [No Email]
Johndeere39h 12-03-2012 15:15:30 66.41.113.151 Report to Moderator	Re: 1948 John Deere M in reply to TJH72, 12-02-2012 09:50:13   I have been having the same problem with my m, only I get spark, then loose it, starts up fine for a few days, Then nothing, no spark, I have replaced the coil, plugs condenser, points, now I'm wondering if I have a short someplace, maybe I should just start replacing the wires....Switch maybe? Any thoughts? Open to any ideas Thanks! [Reply]  [No Email]
nlastovi 12-03-2012 21:49:16 12.238.14.130 Report to Moderator	Re: 1948 John Deere M in reply to Johndeere39h, 12-03-2012 15:15:30   I'd check the coil with a volt meter to make sure that it is getting 6 volts with the switch on. " I get spark, then loose it" makes me wonder if the ignition switch is good and that all connections between the battery and the coil then on to the distributer are clean and making good contact. [Reply]  [No Email]
James Howell 12-03-2012 18:17:11 75.227.132.181 Report to Moderator	Re: 1948 John Deere M in reply to Johndeere39h, 12-03-2012 15:15:30   Does the starter turn the motor over even if the tractor doesn"t start? [Reply]  [No Email]
TJH72 12-04-2012 11:07:12 65.31.36.177 Report to Moderator	Re: 1948 John Deere M in reply to James Howell, 12-03-2012 18:17:11   Yes, The engine turns over but will not start. The inline fuse is good also. Thanks for all of the the help. [Reply]  [No Email]
James Howell 12-02-2012 21:33:04 75.230.169.11 Report to Moderator	Re: 1948 John Deere M in reply to TJH72, 12-02-2012 09:50:13   Checked the Operator"s Manual on page 65 under the FUSE topic. "The fuse is located on lead wire which connects ignition-light switch to ammeter and can be found attached behind a metal clip located at rear of battery on back of instrument panel. If ignition or lights fail, check this fuse. If fuses continue to burn out, check wiring for short circuits. It is important to use a 20 ampere fuse. A smaller or larger capacity fuse will not do." Check to make sure you've got spark from both the spark plugs. Operator's manual suggests .025-inch gap for the spark plugs. Operator's manual suggests .022-inch gap for the points. Hope this helps. [Reply]  [No Email]
Tim14167 12-02-2012 10:46:13 67.247.84.201 Report to Moderator	Re: 1948 John Deere M in reply to TJH72, 12-02-2012 09:50:13   Yes there is an inline fuse. It is located behind the ignition switch, you may have to remove the battery to get to it. Also, as previously stated, check or replace the point and condensor making sure that you set the gap correct is also important [Reply]  [No Email]
donjr 12-02-2012 10:09:47 72.71.175.76 Report to Moderator	Re: 1948 John Deere M in reply to TJH72, 12-02-2012 09:50:13   Take a gander at your points and burnish them up some. [Reply]  [No Email]
